4K UHD9

4K UHD9

Double expanding side semi-trailer.

What’s a Rich Text element?

The rich text element allows you to create and format headings, paragraphs, blockquotes, images, and video all in one place instead of having to add and format them individually. Just double-click and easily create content.

Static and dynamic content editing

A rich text element can be used with static or dynamic content. For static content, just drop it into any page and begin editing. For dynamic content, add a rich text field to any collection and then connect a rich text element to that field in the settings panel. Voila!

How to customize formatting for each rich text
  • Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.
  • ‍Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

Vehicle-Specific Information
  • Dimensions: Truck - 13.2m long x 2.5m wide x 4.3m high; Expander: 10.3m long x 1.1m wide
Production
  • 3ME Sony MVS8350G 1080P Vision Switcher
  • 68 Inputs and 48 Outputs
  • 2-Channels DVE per keyer
Communications
  • Riedel 112 Port System
  • 4 Partyline Beltpack Systems
  • 4 UHF Duplex Base Stations
  • 2 Telephone Hybrid
Cameras
  • 16 Cameras, 5 CCU Positions Plus TD and OB Tech
  • Expandable Sony Ethernet Camera Control
  • 8 Specialty Camera Positions with the Abiltiy to Expand
Support Equipment
  • Evertz Equinox Router
  • HD video - 240 inputs x 224 outputs
  • Equipped with LAWO VSM Control & Monitoring System
  • 4 Utility Frame Syncs/Processors
Audio
  • LAWO Mc56 Mk2
  • 48 Faders, 6 Layers
  • 384 DSP Channels
  • MADI Interfacing
  • Dallis - Fibre Remote Stage Box Interfacing
Record & Playback
  • Up to 6 EVS XT3
  • 1 EVS X-File[3]
  • 1 EVS Xhub[3]
  • HD Digi VTRs
  • HDD/DVD and USB Recorders
HD9 Floor Plan
